Product Information

TIL-1400

This IR drying and curing machine is designed for PU chemicals drying and curing.

Heating section

Section:2 section of heat

IR lamp: 1000W7pcs as a section 

        Total 2 section heater 

IR heating power : 14KW 

IR set: Above belt 

Temperature: 

Room ~120 can be set by require. 

(Within 10 minutes will get 120 degree) 

Heating IR length:600mm 

Temperature Precision; ±5°C

Delivery belt:

Speed : 0-5 M /min 

Material of Belt: Stainless steel 

Belt width: 500mm

Structure of IR belt OVEN:

IR case can be open, easy to continence & replace IR lamps. 

Inner Material: SUS 304 

Loading & unloading Height: 1-250mm 

Safety alarm: Over set temperature will alarm & stop heating automatically 

Loading length: 250mm 

Unloading length: 250mm

Machine outlook

Color:  white with black painted. 

Machine size: 50008001170mm (LWH) 

Power supply: 380VAC 50HZ
